Max.
Armature

HP Range

HP Range

Current

with 115 VAC

with 230 VAC

Model

(Amps DC)

Applied

Applied

DC3R-12D-4X-010-DN

10.0

1/4–1

1/2–2

AC Line Voltage

115/230 VAC, ±10%, 50/60 Hz, single phase

Maximum Allowable Symmetrical AC Line Current

5000 amps

Maximum Line Distribution kVA

115 VAC Input

25 kVA

230 VAC Input

50 kVA

Motor Armature Voltage

115 VAC Input

0–90 VDC

230 VAC Input

0–180 VDC

Form Factor

1.37 at base speed

Field Voltage

115 VAC Input

50 VDC (F1 to L1); 100 VDC (F1 to F2)

230 VAC Input

100 VDC (F1 to L1); 200 VDC (F1 to F2)

Maximum Field Current

1 ADC

Acceleration Time Range (with no load)

0.5–15 seconds

Deceleration Time Range (with no load)

0.5–15 seconds

Analog Input Voltage Range (isolated; RB1 to S2)

–10 to +10 VDC

Input Impedance (RB1 to S2)

32K ohms

Specifications

1
