13 Installation
ATTENTION: Do not connect this equipment with
power applied. Failure to heed this directive may result
in fire or serious injury.
ƽ
Connections
Connect the power input leads and a DC motor to the
drive’s terminal board as shown in Figure 3, page 14.
Ensure that the motor voltage rating is consistent with the
drive’s output voltage.
DC3RD drives supply motor voltage from A1 and A2
terminals. It is assumed throughout this manual that, when
A1 is positive with respect to A2 , the motor will rotate
clockwise (CW) while looking at the output shaft
protruding from the front of the motor. If this is opposite
of the desired rotation, simply reverse the wiring of A1
and A2 with each other.
