Rockwell Automation DC3RD Digital Regenerative DC Drive User Guide 1/4 - 2 HP, 115/230 VAC User Manual
Page 25
17
Installation
Slide switches
ATTENTION:
Change voltage switch settings only
when the drive is disconnected from AC line voltage.
Make sure both switches are set to their correct
position. If the switches are improperly set to a lower
voltage position, the motor will not run at full voltage
and may cause damage to the transformer. If the
switches are improperly set to a higher voltage position,
the motor will overspeed, which may cause motor
damage, or result in bodily injury or loss of life.
ƽ
250-0285-rev1.qxd 4/26/00 9:36 AM Page 17
