Page 23
15
Installation
Field output
The field output is for shunt wound motors only. Do not
make any connections to the field output when using a
permanent magnet motor. See Table 2 for field output
connections.
Table 2. Field Output Connections
Line Voltage
Approximate Field
Field
(VAC)
Voltage (VDC)
Connections
115
50
F1 and L1
115
100
F1 and F2
230
100
F1 and L1
230
200
F1 and F2
250-0285-rev1.qxd 4/26/00 9:36 AM Page 15
