Installation

Table 1. Recommended Line Fuse Sizes

90 VDC Motor 180 VDC Motor Max. DC Armature AC Line Fuse

Horsepower

Horsepower

Current (amps)

Size (amps)

1/20

1/10

0.5

3

1/15

1/8

0.8

3

1/8

1/4

1.5

5

1/6

1/3

1.7

5

1/4

1/2

2.6

8

1/3

3/4

3.5

8

1/2

1

5.0

10

3/4

1 1/2

7.6

15

1

2

10

20
