Limit switch operating modes
The following is a description of the four limit switch
operating modes.
Mode 1 – Half cycle between forward and reverse
limit switches
1. Press the forward pushbutton for
forward motor rotation.
2. Motor rotates in the forward
direction until the forward limit
switch opens.
3. The motor stops when the forward
limit switch opens.
4. Press the reverse pushbutton for
reverse motor rotation
5. Motor rotates in the reverse
direction until the reverse limit
switch opens.
6. The motor stops when the reverse
limit switch opens. Return to step 1
to repeat the process
Press FWD to go forward.
Reverse
Limit
Switch
Forward
Limit
Switch Forward Direction
Reverse Direction
STOP
STOP
Press REV to go reverse.
