Logic board trimpots
FWD JOG
The FWD JOG trimpot setting determines the motor speed
when it rotates in the forward direction in the jog mode. To
calibrate FWD JOG:
1. Press JOG .
2. Press and hold the FWD pushbutton. The motor jogs in
the forward direction.
3. Adjust the FWD JOG trimpot until the motor rotates at
the desired forward jog speed.
4. Release FWD to stop the motor.
REV JOG
The REV JOG trimpot setting determines the motor speed
when it rotates in the reverse direction in the jog mode. To
calibrate REV JOG:
1. Press JOG .
2. Press and hold the REV pushbutton. The motor jogs in
the reverse direction.
3. Adjust the REV JOG trimpot until the motor rotates at
the desired reverse jog speed.
4. Release REV to stop the motor.
38 Calibration
