Jogging the motor
The DC3RD digital drive has a jog option, allowing you to
jog the motor in the forward or reverse direction as long as
the forward or reverse pushbutton is pressed. The drive can
be switched to the jog mode while the motor is stopped, or
is running in either the forward or reverse direction.
To jog the motor:
1. Press JOG to enter the jog mode.
2. To jog the motor in the forward direction:
a. Press and hold the FWD pushbutton. The motor
jogs in the forward direction. The motor speed is
set by the FWD JOG trimpot.
b. Release FWD to stop the motor.
To jog the motor in the reverse direction:
a. Press and hold the REV pushbutton. The motor jogs
in
the reverse direction. The motor speed is set by the
REV JOG trimpot.
b. Release REV to stop the motor.
3. To exit the jog mode, press STOP.
23 Operation
