Alarms
Number
Alarm Parameters
Operators
Hysteresis
Startup Inhibit/Setpoint Multiplication
Speed Inhibit
12 alarm and danger pairs
Speed, Overall, DC Bias, Band or Tracked
Magnitude from either channel
Greater than
Less than
Inside range
Outside range
User configurable in software
Period: 0 to 1092 minutes, adjustable in 0.1
minute increments
Inhibit/multiplication function: floating
point value in the range of 0 to 10
A speed range may be specified for each
alarm. When applied, the alarm is disabled
when speed is outside of the defined range.
Relays
Number
On-board Relay Rating
Failsafe
Latching
Time Delay
Single on-board relay, two sets of contacts -
DPDT (2 Form C)
Four additional relays when interconnected
to an XM-441 Expansion Relay module, or
Four virtual relays whose status can be
used by remote Control Systems or the
XM-440 Master Relay module
Maximum Voltage: 120V dc, 125V ac
Maximum Current: 3.5 A*
Minimum Current: 0
Maximum Power: 60 W, 62.5 VA
*Max current is up to 40°C, then derates to 2 A
at 65°C
Agency Rating:
120V ac @ 0.5 A
110V dc @ 0.3 A
30V dc @ 1.0 A
Normally energized (failsafe), or
Normally de-energized (non-fail-safe)
Latching, or
Non-latching
0 to 65.53 seconds, adjustable in 0.01
second increments
XM-123 Technical Specifications
Product Feature
Specification
