Rockwell Automation 1440-VAD02-01RA XM-123 Aeroderivative Module - Manual (Page 129)

Publication GMSI10-UM003D-EN-P - May 2010
121
6 Get Threshold Units USINT Indicates whether the
threshold and hysteresis
value are specified in
units of measure. Set to 1
1 = Measurement units
7 Get/Set Condition USINT Indicates on which side of
the threshold values the
alarm and danger
conditions exist. 0 = Greater than
1 = Less than
2 = Inside range
3 = Outside range
8 Get/Set Alert Threshold
(High) REAL The threshold value for
the alert (alarm) condition
(greater threshold for
range types).
9 Get/Set Danger
Threshold (High) REAL The threshold value for
the danger (shutdown)
condition (greater
threshold for range types).
10 Get/Set Alert Threshold
Low REAL The lesser threshold value
for the alert (alarm)
condition for the range
condition types.
11 Get/Set Danger
Threshold
Low REAL The lesser threshold value
for the danger (shutdown)
condition for the range
condition types.
12 Get/Set Hysteresis REAL The amount on the safe
side of a threshold by
which the value must
recover to clear the alarm.
13 Get/Set Threshold
(Setpoint
Multiplier) REAL Indicates how the
thresholds should be
adjusted when the
setpoint multiplication
function is invoked. 0 = Disable alarm
> 0 = Multiply the thresholds by
the value
14 Get/Set Startup Period UINT The amount of time that
the Threshold (Setpoint)
Multiplier is applied after
the startup signal is
received. Seconds
15 Get/Set Speed Range
Enable BOOL Indicates whether this
alarm is enabled only
within a certain machine
speed range. 0 = No speed range (alarm is
always enabled)
1 = Speed range (alarm only
enabled within speed range)
16 Get/Set Speed Range
High REAL Indicates the greater
threshold of the machine
speed range for which the
alarm is enabled (disabled
at greater speeds). CPM
(must be greater than Speed
Range Low)
Table C.28 Alarm Object Instance Attributes
Attr ID
Access
Rule
Name Data Type Description Semantics
