Poll Size Sets the size (number of bytes) of the Poll response
message. Decreasing the maximum size will truncate
data from the end of the Assembly structure.
Important: If you set the Poll Output to "Custom
Assembly," the poll size is automatically set to the
actual size of the customized Poll response.
The minimum size is 4 bytes and the
maximum size is 124 bytes.
Sets the Assembly instance used for the Poll
response message. Each Assembly instance contains
a different arrangement of the Poll data.
The Poll response message is used by the XM
module to produce measured values. It can contain
up to 31 REAL values for a total of 124 bytes of data.
Options: Assembly Instance 101
Assembly Instance 102
Custom Assembly
Refer to Poll Message Format on
page 93 for more information.
Assembly Instance Table (XM
Serial Configuration Utility only) Displays the format of the currently selected COS or
Poll Assembly instance. The highlighted (yellow) Assembly
structure bytes are included in the I/O
message.
Custom Assembly (XM Serial
Configuration Utility only) Defines a custom data format for the Poll response.
The custom assembly can contain any of the
measurement parameters included in Assembly
instance 101, as well as alarm and relay
configuration parameters. You can select up to 20 parameters.
Refer to Poll Message Format on
page 93 for more information.
I/O Data Parameters
Parameter Name Description Values/Comments
XM Configuration
Utility EDS File
Poll Output Poll
Response
Assembly
