Planning Before Installing 3-9
3.2.4 Meeting Encoder Specifications (FVC Regulation Only)
GV3000/SE drives set up for FVC regulation require an encoder for closed-loop
operation. Refer to table A.5 for specifications. Drives set up for V/Hz or SVC
regulation do not require an encoder for feedback.
3.2.4.1 Encoder Wiring Guidelines
Encoder connections are considered signal level wiring and, therefore, must be run
separate from control and power wiring. Reliance Electric recommends 18 AWG
unshielded twisted pair wires with 2-3 twists per inch for applications to a maximum
distance of 303 meters (1000 feet). The recommended Reliance Electric part number
is 417900-207CG; 18 AWG, 6 conductor (3 twisted pairs).
3.2.5 Verifying Power Module Output Current Rating Is Greater Than
Motor Full Load Amps
Verify that the GV3000/SE output current rating is greater than the motor’s full load
current (amps). Table 2.1 lists the output current values.
300ER40xx 896.09.11 No 38 A
50 A 50 A
300ET40xx 896.09.31 Yes 32 A
430ER40xx 896.11.12 No 53 A
63 A 63 A
430ET40xx 896.11.32 Yes 47 A
1 AC line input current (RMS) is dependent on total line impedance.
2 Recommended type of external input fuse:
AC line input: Branch circuit protection fuse, e.g., IEC 269-1/gG, EN 60269-1, VDE 0636/gL, UL Class
J, or equivalent.
DC bus input: Semiconductor protection fuse, 660 V or 750 V, superfast, e.g., A70P500, VDE 0636/aR,
or equivalent.
Table 3.10 – AC Input Fuse Selection Values (Continued)
U.S.
Model
Number
European
Stock
Number Choke
AC Input
Current 1
External Fuse 2
Nominal Maximum
