1-4 WebPak 3000 DC Drive Hardware Reference
1.6 Optional Kits
Rockwell Automation offers modification kits that broaden the application range of the drive.
A summary of these kits is presented in Table 1.2. For US Model-No's refer to Appendix C.
Table 1.2 - Drive Modification Kits
Name Description
Part Number
Catalog-No. Instruct. Manual
Manual No.
Publication No. 1)
Pulse Encoder
Feedback Kit
(incl. cable) Allows for digital pulse Encoder speed
feedback. 762.70.00
PTK
49’1343
FP3TIF-UM002B-EN
AutoMax Network
Communication
kit (board &
cable) Allows the WebPak 3000 to communicate on
the Reliance AutoMax Distributed Control
System (DCS). 762.70.40
AMXF
D2-3318
D2-3318
IBSF Communic.
kit (board & cable) Allows the WebPak 3000 to communicate
over the standardized field bus system
INTERBUS. 762.70.45
IBSF
49’1339
FP3IBS-UM003C-EN
PDPF Communic.
kit (board & cable) Allows the WebPak 3000 to communicate
over the standardized Profibus-DP system. 762.70.95
PDPF
49’1348
FP3PDP-UM002B-EN
ControlNet
Communication
Board Allows a WebPak to communicate over the
open protocol ControlNet network.
Mounts inside the WebPak and includes
terminals for network connections.
The AMX Network Comm. board cannot be
used when using the ControlNet. 762.70.96
CONF
D2-3425
D2-3425
Drive Control
Configuration
Software
WebPakCS Windows-based software that allows the user
to connect any personal computer running
Micro-soft Windows version 3.1 or later to a
WebPak 3000 drive. Allows you to create,
store, upload, and download drive
configurations. You can also monitor and
change parameters through the PC and read
and reset the drive’s fault log. D2-3447
D2-3447
Interface Cable for connecting the drive to PC (25-pin to 9-pin) 772.27.00
61C127
Keypad Operator
Interface Module Allows you to control (e.g. Start, Stop, Jog)
the drive. You can also monitor and change
parameters, read and clear the drive's alarm
and fault log. 922.95.01
OIM-WEB
D2-3445
D2-3445
OIM Remote
Mounting kit Provides for remote mounting of the OIM up
to 5 meters away from the drive. Contains
also the cover plate (762.70.31) for the
regulator unit. 762.70.30
DMK
D2-3294
D2-3294-1
1) Manuals with Publication Number FP3xxx or D2-xxxx can be ordered in the Automation Bookstore
or downloaded via www.theautomationbookstore.com, than Public – Item search, Go - Item
Number: begins with: e.g. FP3 or D2-3445 - search.
