PowerFlex 1203-USB Converter User Manual
Publication DRIVES-UM001D-EN-P
Appendix C
Use with DriveExplorer Software
This appendix presents information about using DriveExplorer software
with the 1203-USB converter.
Important: Please note that there are no plans to provide future updates to
this tool and it is being provided ‘as-is’ for users that lost their
DriveExplorer CD, or need to configure legacy products not
supported by Connected Components Workbench software.
Installing DriveExplorer
Software
The full version of DriveExplorer software is available from the Rockwell
Automation website at
http://www.ab.com/support/abdrives/webupdate/
software.html . After downloading the DriveExplorer software to your
desktop, double-click its executable file to display the DriveExplorer Setup
screen and follow the screen prompts to install the software.
!
ATTENTION: DriveExplorer software does not support and must
not be used with PowerFlex 520-Series drives. Although a
DSI-based drive like the PowerFlex 4-Class drives, it has several
new features not supported by DriveExplorer software. Saving a
configuration using DriveExplorer software will be incomplete
and data will be lost. Use Connected Components Workbench
software with PowerFlex 520-Series drives.
Topic Page
Installing DriveExplorer Software C-1
Configuring the Converter C-2
Resetting the Converter C-4
Preparing for a Firmware Update C-4
Updating the Firmware C-5
Troubleshooting C-5
Using RTU Master Mode for a Serial Multi-drop Network C-8
