B-4 Converter Parameters
PowerFlex 1203-USB Converter User Manual
Publication DRIVES-UM001D-EN-P
Parameters – SCANport
Drives (DriveExplorer or
DriveExecutive software
only)
No. Name and Description Details
01 [Adapter Port]
Displays the port on the host drive to which the
converter is connected.
Default: 0
Minimum: 0
Maximum: 7
Type: Read Only
02 [Reset Module]
No action if set to ‘0’ (Ready). Resets the converter if
set to ‘1’ (Reset Module). Restores the converter to its
factory default settings if set to ‘2’ (Set Defaults). This
parameter is a command. It will be reset to ‘0’ (Ready)
after the command has been performed.
Default: 0 = Ready
Values: 0 = Ready
1 = Reset Module
2 = Set Defaults
Type: Read/Write
Reset Required: No
03 [Clear DF1 Counts]
No action if set to ‘0’ (Ready). Resets the DF1
statistical Parameter 04 - [DF1 Packets Sent] and
Parameter 05 - [DF1 Packets Rcvd] to 0 (zero) if set
to ‘1’ (Clear Counts). This parameter is a command. It
will be reset to ‘0’ (Ready) after a ‘Clear Counts’
command has been performed.
Default: 0 = Ready
Values: 0 = Ready
1 = Clear Counts
Type: Read/Write
Reset Required: No
04 [DF1 Packets Sent]
Displays the number of DF1 packets sent by the
converter. The value of this parameter is normally
approximately equal to the value of Parameter 05 -
[DF1 Packets Rcvd].
Default: 0
Minimum: 0
Maximum: 65535
Type: Read Only
05 [DF1 Packets Rcvd]
Displays the number of DF1 packets received by the
converter. The value of this parameter is normally
approximately equal to the value of Parameter 04 - [DF1
Packets Sent].
Default: 0
Minimum: 0
Maximum: 65535
Type: Read Only
06 [Interface Mode]
Sets the interface operating mode.
Auto:
The converter will automatically run DPI if
connected to a DPI drive, or SCANport if
connected to a SCANport drive.
SCANport: The converter will perform SCANport
services only.
Set this parameter to ‘0’ (Auto, the default) unless you
are using DriveTools32 software, version 2.xx, and you
are connected to a DPI drive. In this case, use the ‘1’
(SCANport) setting.
Default: 0 = Auto
Values: 0 = Auto
1 = SCANport
Type: Read/Write
Reset Required: Yes
!
ATTENTION: Risk of injury or equipment damage exists. If the converter is
transmitting I/O that controls the drive (indicated by a steady green diamond
status indicator), the drive may fault when you remove or reset the converter.
Determine how your drive will respond before removing or resetting a connected
converter.
