4-2 Troubleshooting
PowerFlex 1203-USB Converter User Manual
Publication DRIVES-UM001D-EN-P
Diamond Status Indicator
RX Status Indicator
TX Status Indicator
!
ATTENTION: Risk of injury or equipment damage exists. If the
converter is transmitting control I/O to the drive (indicated by a
steady green diamond status indicator), the drive may fault when
you remove or reset the converter. Determine how your drive will
respond before removing or resetting a converter.
Status Cause Corrective Action
Off Converter is not powered, or is in
Flash programming mode.
• Securely connect cables.
• Apply power to the drive.
• Wait until Flash update is completed.
Flashing
Green
Converter is operating and not
transmitting control I/O.
No action required. Removing or resetting the
converter will not cause a fault in the drive.
Steady
Green
Converter is operating and is or
was transmitting control I/O.
No action required. Removing or resetting the
converter will cause a fault in the drive.
For DPI drives only, a ‘Soft Logout’ can be
performed to allow removal of the converter without
a fault occurring. To do this, set the logic mask in the
drive to ignore the converter and then verify that the
drive is receiving its Logic Command and Reference
from another source.
Flashing
Red
The drive has not acknowledged
the converter.
• Securely connect cables.
• DPI or SCANport Drives:
Verify that converter Parameter 06 - [Interface
Mode] is set to ‘0’ (Auto).
• DSI Drives:
Verify that converter Parameter 01 - [Adapter
Cfg] is set to ‘0’ (Auto).
The drive was disconnected from
the computer, or the computer was
turned off.
• Securely connect cables.
• Turn on the computer.
Steady
Red
Link failure. • Securely connect cables.
• Replace the cable.
• Cycle power to the drive.
Status Cause Corrective Action
Off Converter is not receiving data. • Verify that data is being transmitted by the
computer.
• Securely connect cables.
• Apply power to the drive.
• Configure the computer software to use the same
port rate as the converter.
Flashing
Green
Converter is receiving data from the
computer.
No action required.
Status Cause Corrective Action
Off Converter is not transmitting data. • Verify that data is being transmitted.
• Securely connect cables.
• Apply power to the drive.
Flashing
Green
Converter is transmitting data to the
computer.
No action required.
