Troubleshooting 4-7
PowerFlex 1203-USB Converter User Manual
Publication DRIVES-UM001D-EN-P
Event Codes for DSI Drives
Event Codes for SCANport Drives
(DriveExplorer or DriveExecutive software only)
Code Event Description
F0 No Event No event present in the event queue.
F1 Adapter Reset The converter was reset by the user.
F2 Slave Detected A slave was detected to be present by the master.
F3 Slave Removed A slave was detected to be removed by the master.
F4 Host Timeout A timeout condition on Msg to Host.
F5 Slave Timeout A timeout condition on Msg to Slave.
F6 Master Timeout A timeout condition on Msg to Master.
F7 Serial Timeout A timeout on Serial 232 side (with control enabled).
F8 Control Enabled The converter has sent a ‘Soft Control Enable’ command to the drive.
F9 Control Disabled The converter has sent a ‘Soft Control Disable’ command to the drive.
F10 EEPROM Sum Flt Startup sequence detected corrupt EEPROM storage in the converter.
Events Description
Adapter Reset The converter was reset or power cycled.
Clear SP Fault The SCANport drive issued this because a fault was cleared in it.
Clear SP Warning The SCANport drive issued this because a warning was cleared.
Empty Queue The queue does not contain any recorded events.
Message Timeout The SCANport drive did not respond to a message request. Verify that cabling
is correct.
No SCANport Ping The converter issued this because no SCANport pings were detected within a
2 second period. This event may be caused by a disconnected or broken
cable, a broken converter, or a malfunction in the SCANport drive.
Pin ID Change The converter issued this because the SCANport Pin ID was changed. This
event is normal after a power cycle or reset.
SCANport Bus Off The converter issued this because its SCANport CAN chip went bus off. This
event may be caused by loose or broken cables, or by noise.
SCANport Fault The SCANport drive issued this because it was faulted. See its fault queue.
SCANport Reset The SCANport drive issued this because it was reset.
SCANport Warning The SCANport drive issued this because it had a warning.
SP Pin ID = 7 The converter issued this because its Pin ID has a value of 7. It should have a
value between 1 and 6. This event may be caused by a loose or broken cable.
