Transferring Application Files with

Chapter 5

User PROMs

5-5

To burn a single EPROM for Series D, E and F terminals:

Connect your computer to an EPROM burner with an RS-232 serial
cable.

The EPROM burner is connected to the same RS-232 port on the
development computer that is used to connect the PanelView 1200
terminal. Refer to your EPROM burner user’s manual for connection
instructions.

Start the PanelView 1200 Transfer Utility.

Open the Transfer menu.

Choose Burn Single EPROM from the Transfer menu.

Choose Select Application File and select the application you want to
download to the EPROM burner. Press

ENTER

If the file is greater than 64K, a warning message appears: “This
application exceeds the memory limit (64K) for hex files or PROMs.
Delete one or more objects, messages, or screens to reduce size to 64K
or less”.

PanelBuilder takes a few seconds to generate the hex file. When the file
is created, a message appears, informing you that the hex files have been
generated successfully. The Burn FILENAME menu opens, (where
FILENAME is the name of the application you selected).

23625

MAIN MENU:

Screens

Windows

Options

Communic

Exit

Transfer

Download to PanelView (RS-232)

Upload from PanelView (RS-232)

Pass-Through Download to PanelView (DH+ and Remote I/O)

Pass-Through Upload from PanelView (DH+ and Remote I/O)

Burn EPROMS

Burn Single EPROM

Quit

Burn Single EPROM

Select Application File

EXAMPLE

Select Hex File

EXAMPLE

Generate Hex Files

EXAMPLE
