Transferring Via the Data Highway Plus
Chapter 4
and Remote I/O
4-10
Installing PCMK Drivers for 6200 Software
The 1784-KT driver enables you to use the 1784-PCMK card. Before you
can use the 1784-PCMK card, you must install the PCMK drivers for 6200
software. For installation instructions, see your 6200 software user manual.
When 6200 software is working, copy the following files from the
\PASSTHRU\PCMK directory to the \PASSTHRU directory:
KLPCL.BIN
KLSTO.BIN
KLST1.BIN
KLST2.BIN
These files will overwrite the files of the same name that are already in the
directory. You can now upload or download as usual.
To use a 1784-KT card instead of the 1784-PCMK card, copy the files
listed previously from the \PASSTHRU\KT directory to the \PASSTHRU
directory. They will overwrite the PCMK files.
Defining Programming Terminal Configuration Parameters
To define the programming terminal configuration:
1 Choose Programming Terminal Configuration from the Pass-Through
Download to PanelView (DH+ and Remote I/O) menu.
The Programming Terminal Configuration menu appears. Here you can
configure your computer’s communications.
22573
Programming Terminal Configuration
Programming Terminal DH+ Addres 0
DH+ Hardware Driver 1770-KF2/1785-KE
Pass-Through Utility Directory C:\AB\PB1200\PTU\PASSTHRU
Quit
2 Configure the parameters as follows:
a Enter a value (between 0–77 octal) for the Programming Terminal
DH+ Address.
b Choose DH+ Hardware Driver, select the appropriate driver and
configure it as required.
