Transferring Application Files Serially
Chapter 3
3-5
23639
Develop Transfer Reports FilesCopy File Exit Transfer
Download to PanelView (RS-232)
Upload from PanelView (RS-232)
Pass-Through Download to PanelView (DH+ and Remote I/O)
Pass-Through Upload from PanelView (DH+ and Remote I/O)
Burn EPROMS
Burn Single EPROM
Quit
6 Choose Select File to select the application you want to download. A
window appears, displaying the applications in that directory.
23639
AIN MENU Develop Transfer Reports FilesCopy File S Exit Transfer
Download to PanelView (RS-232)
Upload from PanelView (RS-232)
Pass-Through Download to PanelView (DH+ and Remote I/O)
Pass-Through Download to PanelView (DH+ and Remote I/O)
Burn E
Burn Single EPROM
Quit
Download to PanelView (RS-232)
Select File EXAMPLE1
Directory C:\PDS
Quit
EXAMPLE1 13:37:22 05/28/94 16985 bytes
EXAMPLE2 09:44:10 05/28/94 17201 bytes
EXAMPLE3 11:36:03 05/18/94 17045 bytes
If no *.CFG application files exist in the current directory, choose
Directory and type in the correct drive and directory. Then, choose
Select File again.
Important You can download application files with *.CFG file
extensions only. If you want to download application files created in
PanelBuilder 1200 for Windows, you must first save them as *.CFG
files. See your PanelBuilder 1200 Configuration Software for Windows
User Manual for more information.
7 Move your cursor to highlight the application you want to download and
press
ENTER.
