Transferring Application Files Serially
Chapter 3
3-6
The Select File menu appears.
8 Choose Configure Port.
9 Choose COM1 or COM2 port.
The following table shows the Upload/Download Communication
settings available for the PanelBuilder application.
Port COM1 COM2
Baud Rate 300 600 1200 2400 4800 *9600 19200
Parity Type odd even *none
Data Bits 7 *8
Stop Bits *1 2
*default settings
10 Make changes if you wish, but ensure that the settings are the same as
those on the PanelView 1200 terminal.
Important Although you can choose from between 7 or 8 data bits,
always choose 8, or your transfer will not be successful. The 7 data bit
option applies only if you’re configuring the port for printing.
Tip Before you actually begin downloading, check the application file
size in the Select File menu. This lets you ensure that there is enough
available memory in the PanelView 1200 terminal to load the
application file.
11 Choose Download FILENAME (where FILENAME is the name of the
selected application).
22116
AIN MENU Develop Transfer Reports FilesCopy File Exit Transfer
Download to PanelView (RS-232)
Upload from PanelView (RS-232)
Pass-Through Download to PanelView (DH+ and Remote I/O)
Pass-Through Download to PanelView (DH+ and Remote I/O)
Burn E
Quit
Download to a PanelView Terminal
Select File EXAMPLE1
Directory C:\PDS
Quit
EXAMPLE1 13:37:22 05/28/90 16985 bytes
EXAMPLE2 09:44:10 05/28/90 17201 bytes
EXAMPLE3 11:36:03 05/18/90 17045 bytes
Select File
Download EXAMPLE1
Configure Port COM1
Application Size
Quit
12 Choose Yes and press ENTER when prompted to start downloading. You
can cancel the transfer any time by pressing ESC.
