Appendix D
Configuration Data
D–14
Table D.11
Configuration Blocks #110, 112 . . . & 204 – Windows 1–48
Remote I/O
& RS–232
Word #
Bit # Definition Usage Notes
15 0–15 Fail Range High (Integer)
Words 15 and 16 represent a 16 (bit).16 (bit)
fixed point decimal value or 32 bit integer.
16 0–15 Fail Range High (Fraction)
17 0–15 Fail Range Low (Integer)
Words 17 and 18 represent a 16 (bit).16 (bit)
fixed point decimal value or 32 bit integer.
18 0–15 Fail Range Low (Fraction)
19 0–15
Warning Range High
(Integer) Words 19 and 20 represent a 16 (bit). 16 (bit)
fixed point decimal value or 32 bit integer.
20 0–15
Warning Range High
(Fraction)
21 0–15
Warning Range Low
(Integer) Words 21 and 22 represent a 16 (bit).16 (bit)
fixed point decimal value or 32 bit integer.
22 0–15
Warning Range Low
(Fraction)
23 0–15 Reserved
Note: Each window needs two blocks for the description:
Block #110 describes window #1 (Part 1)
Block #111 describes window #1 (Part 2)
Block #112 describes window #2 (Part 1)
. . .
Block #204 describes window #48 (Part 1)
Block $205 describes window #48 (Part 2)
Table D.12
Configuration Block #111, 113 . . . & 205 – Windows 1–48
Remote I/O
& RS–232
Word #*
Bit # Definition Usage Notes
0 0–15 Block Transfer Signature
1–55 0–15 Reserved
Configuration Blocks 110–205
(cont’d)
