(Host Input & Output Bits)
Appendix B
Discrete Bit Results Bits
B–15
Table B.1
Discrete Bit Inputs (Cont’d)
PI Backplane Remote I/O RS–232 ASCII RS–232 DF1
Word
#
Bit #
Word
#
Bit #* Hex # Bit #
Byte
#
Bit #
Definition Usage Notes
28 8 4 10 27 0 32 0
Gage 37
Warning Flag
0 = Pass
1 = Fail
28 9 4 11 27 1 32 1
Gage 37
Fault Flag
0 = Pass
1 = Fail
28 10 4 12 27 2 32 2
Gage 38
Warning Flag
0 = Pass
1 = Fail
28 11 4 13 27 3 32 3
Gage 38
Fault Flag
0 = Pass
1 = Fail
28 12 4 14 27 4 32 4
Gage 39
Warning Flag
0 = Pass
1 = Fail
28 13 4 15 27 5 32 5
Gage 39
Fault Flag
0 = Pass
1 = Fail
28 14 4 16 27 6 32 6
Gage 40
Warning Flag
0 = Pass
1 = Fail
28 15 4 17 27 7 32 7
Gage 40
Fault Flag
0 = Pass
1 = Fail
29 0 5 0 28 0 35 0
Gage 41
Warning Flag
0 = Pass
1 = Fail
29 1 5 1 28 1 35 1
Gage 41
Fault Flag
0 = Pass
1 = Fail
29 2 5 2 28 2 35 2
Gage 42
Warning Flag
0 = Pass
1 = Fail
29 3 5 3 28 3 35 3
Gage 42
Fault Flag
0 = Pass
1 = Fail
29 4 5 4 28 4 35 4
Gage 43
Warning Flag
0 = Pass
1 = Fail
29 5 5 5 28 5 35 5
Gage 43
Fault Flag
0 = Pass
1 = Fail
29 6 5 6 28 6 35 6
Gage 44
Warning Flag
0 = Pass
1 = Fail
29 7 5 7 28 7 35 7
Gage 44
Fault Flag
0 = Pass
1 = Fail
