Appendix C
Numerical Results Data
C–10
Table C.3
Numerical Results Data–Results Block 2 (cont’d)
Word #
PI
Backplane
RS–232
and
Remote
I/O
Bit # Definition Usage Notes
204 44 0–15
Reference Window #3
Theta (Integer)
16.16 value. Refer to Appendix A. Only if
2 or 3 Features are enabled.
205 45 0–15
Reference Window #3
(Fraction)
Only if 2 or 3 Features are enabled.
206 46 0
Reference Window X1/Y1
Pass/Fail Bit
0 = Pass
1 = Fail
Feature #1 16 Bit integer
206 46 1
Reference Window X2/Y2
Pass/Fail Bit
0 = Pass
1 = Fail
Feature #2 16 Bit integer
206 46 2
Reference Window X3/Y3
Pass/Fail Bit
0 = Pass
1 = Fail
Feature #3 16 Bit integer
206 46 3 Combination Pass/Fail Bit
0 = Pass
1 = Fail
0 if all enabled tools pass.
206 46 4–15 Not Used
207 47 0–15
Score Reference Window #3
Feature #1
208 48 0–15
Score Reference Window #3
Feature #2
209 49 0–15
Score Reference Window #3
Feature #3
210 50 0–15 Brightness Probe Red Integer 16.16 value
211 51 0–15
Brightness Probe
Red Fraction
16.16 value
212 52 0–15
Brightness Probe
Green Integer
16.16 value
213 53 0–15
Brightness Probe
Green Fraction
16.16 value
214 54 0–15 Brightness Probe Blue Integer 16.16 value
215 55 0–15
Brightness Probe
Blue Fraction
16.16 value
216–217 56–57 0–15 Reserved
218 58 0–15 Reserved
219 59 0–15 Task Missed Triggers 16 Bit integer
220 60 0–15
Task Master Faultsr — Most
Significant Word
32 Bit Integer. Increments if at least 1 tool
fails.
221 61 0–15
Task Master Faultsr — Least
Significant Word
222 62 0–15
Task Triggersr — Most
Significant Word
32 Bit Integer.
223 63 0–15
Task Triggersr — Least
Significant Word
Results Block #3 (cont’d)
