Appendix C
Numerical Results Data
C–8
Table C.3 shows the function of each word in results block #3.
Table C.3
Numerical Results Data– Results Block 3
Word #
PI
Backplane
RS–232
and
Remote
I/O
Bit # Definition Usage Notes
160 0 0–15 Block Transfer Signature
161 1 0–15 Reserved
162–163 2–3 0–15 Gage #23 Value
Angular & Linear
Measure 16.16
Edge–32 bit integer
Object–32 bit integer
Pixel–32 bit integer
Color Match–32 bit integer
Color ID–32 bit integer
X Position & Y Position–16.16
164–165 4–5 0–15 Gage #24 Value Same as gage #23
166–167 6–7 0–15 Gage #25 Value Same as gage #23
168–169 8–9 0–15 Gage #26 Value Same as gage #23
170–171 10–11 0–15 Gage #27 Value Same as gage #23
172–173 12–13 0–15 Gage #28 Value Same as gage #23
174–175 14–15 0–15 Gage #29 Value Same as gage #23
176–177 16–17 0–15 Gage #30 Value Same as gage #23
178–179 18–19 0–15 Gage #31 Value Same as gage #23
180–181 20–21 0–15 Gage #32 Value Same as gage #23
182 22 0–15
Reference Window #2
X1 Position
Feature #1 16 Bit Integer
183 23 0–15
Reference Window #2
Y1 Position
Feature #1 16 Bit Integer
184 24 0–15
Reference Window #2
X2 Position
Feature #2 16 Bit Integer
185 25 0–15
Reference Window #2
Y2 Position
Feature #2 16 Bit Integer
186 26 0–15
Reference Window #2
X3 Position
Feature #3 16 Bit Integer
187 27 0–15
Reference Window #2
Y3 Position
Feature #3 16 Bit Integer
Results Block #3
