Rockwell Automation 5370 Color CVIM Communications Manual - Manual (Page 165)

(Host Input & Output Bits)
Appendix B
Discrete Bit Results Bits
B–11
Table B.1
Discrete Bit Inputs (Cont’d)
PI Backplane Remote I/O RS–232 ASCII RS–232 DF1
Word
#
Bit #
Word
#
Bit #* Hex # Bit #
Byte
#
Bit #
Definition Usage Notes
24 8 0 10 19 0 24 0
Reference Line
1 Flag
0 = Pass
1 = Fail
24 9 0 11 19 1 24 1
Reference Line
2 Flag
0 = Pass
1 = Fail
24 10 0 12 19 2 24 2
Reference Line
3 Flag
0 = Pass
1 = Fail
24 11 0 13 19 3 24 3
Reference
Window 1 Flag
0 = Pass
1 = Fail
24 12 0 14 19 4 24 4
Reference
Window 2 Flag
0 = Pass
1 = Fail
24 13 0 15 19 5 24 5
Reference
Window 3 Flag
0 = Pass
1 = Fail
24 14 0 16 19 6 24 6 Light Probe Flag
0 = No Fault
1 = Fault
24 15 0 17 19 7 24 7 Master Fault
0 = Pass
1 = Fail Master Fault bit is set if any tool
fails an inspection.
25 0 1 0 20 0 27 0
Window 25
Warning Flag
0 = Pass
1 = Fail
25 1 1 1 20 1 27 1
Window 25
Fault Flag
0 = Pass
1 = Fail
25 2 1 2 20 2 27 2
Window 26
Warning Flag
0 = Pass
1 = Fail
25 3 1 3 20 3 27 3
Window 26
Fault Flag
0 = Pass
1 = Fail
25 4 1 4 20 4 27 4
Window 27
Warning Flag
0 = Pass
1 = Fail
25 5 1 5 20 5 27 5
Window 27
Fault Flag
0 = Pass
1 = Fail
25 6 1 6 20 6 27 6
Window 28
Warning Flag
0 = Pass
1 = Fail
25 7 1 7 20 7 27 7
Window 28
Fault Flag
0 = Pass
1 = Fail
