D Appendix
D–1
Configuration Data
There are 213 configuration blocks. The following is an overview of the
blocks.
Block Number 1 System Environment . . . . . . . . . . . . . . . . . .
(42 words).
Block Number 2 Camera Definition Part 1 . . . . . . . . . . . . . . . . . .
(50 words).
Block Number 3 Camera Definition Part 2 . . . . . . . . . . . . . . . . . .
(36 words).
Block Numbers 4 through 35 Colors Definition 1 through 32 . . . . . . . .
(14 words).
Block Number 36 Gray Scale Definition . . . . . . . . . . . . . . . . .
(8 words).
Block Numbers 37 through 39 Reference Lines 1 through 3 . . . . . . .
Part 1 (30 words).
Block Numbers 40, 42, and 44 Reference windows 1 through 3 . . . . . . .
Part 1 (9 words).
Block Numbers 41, 43, and 45 Reference windows 1 through 3 . . . . . . .
Part 2 (59 words).
Block Numbers 46 to 109 Gages 1 through 64 . . . . . . . . . . .
(28 words).
Block Numbers 110, 112 & 204 Windows 1 through 48 Part 1 . . . . . .
(24 words).
Block Numbers 111, 113 & 205 Windows 1 through 48 Part 2 . . . . . .
(56 words).
Block Numbers 206 through 213 Polygon Blocks 1 through 8 . . . . .
(35 words).
Note: When reading the configuration blocks, the PLC should set the block
length to 0. This will allow the Color CVIM module to set the block size
based upon the block number received. The Color CVIM module will then
only send the amount of data required for each block type. This helps reduce
the overall transfer time when writing. If the PLC sets the block length to 0
(64 words) when writing to a Color CVIM module, the Color CVIM module
will ignore excess data at the end of each block. Alternatively, the PLC may
set the exact length to reduce the transfer time.
Configuration Block Overview
