Appendix C
Numerical Results Data
C–19
Word # Bit # Byte #
Function
Bit #
7 13 Gage 38 11 5
7 14 Gage 39 11 6
7 15 Gage 40 11 7
8 0 Gage 41 12 0
8 1 Gage 42 12 1
8 2 Gage 43 12 2
8 3 Gage 44 12 3
8 4 Gage 45 12 4
8 5 Gage 46 12 5
8 6 Gage 47 12 6
8 7 Gage 48 12 7
8 8 Gage 49 13 0
8 9 Gage 50 13 1
8 10 Gage 51 13 2
8 11 Gage 52 13 3
8 12 Gage 53 13 4
8 13 Gage 54 13 5
8 14 Gage 55 13 6
8 15 Gage 56 13 7
9 0 Gage 57 14 0
9 1 Gage 58 14 1
9 2 Gage 59 14 2
9 3 Gage 60 14 3
9 4 Gage 61 14 4
9 5 Gage 62 14 5
9 6 Gage 63 14 6
9 7 Gage 64 14 7
9 8 Not Used 15 0
9 9 Not Used 15 1
9 10 Not Used 15 2
9 11 Not Used 15 3
9 12 Not Used 15 4
9 13 Not Used 15 5
9 14 Not Used 15 6
9 15 Not Used 15 7
