(Host Input & Output Bits)
Appendix B
Discrete Bit Results Bits
B–19
There are 128 bits that can be set as outputs from a host device to control the
operation of the Color CVIM. These bits control:
•
Monitor display.
•
Camera trigger.
•
Toolset selection.
•
I/O forcing.
•
Selection of operation after reject.
•
Memory storage location. RAM, EEPROM, RAM Card, or external host
memory.
Refer to Tables B.2 and B.3. Table B.2 only applies to Backplane
communications. Table B.3 applies to both Backplane and Remote I/O
communications.
Table B.2
Backplane Handshake Bits
Word #
PI
Backplane
RS–232
and
Remote
I/O
Bit #
PI
Definition Usage Notes
0 N/A 0 Host Data Lock
0 = Color CVIM May Write
1 = Color CVIM Write
Inhibited
The backplane host should write to bit 0 to prevent
the Color CVIM from modifying results data.
0 N/A 1 Reserved
0 N/A 2 Color CVIM Data Lock
0 = Color CVIM Not Writing
1 = Color CVIM Writing The Color CVIM sets bit 2 while writing. The bit will
be set back to 0 after writing.
0 N/A 3 Reserved
0 N/A 4–15 Reserved
Discrete Bit Outputs
