(Host Input & Output Bits)
Appendix B
Discrete Bit Results Bits
B–14
Table B.1
Discrete Bit Inputs (Cont’d)
PI Backplane Remote I/O RS–232 ASCII RS–232 DF1
Word
#
Bit #
Word
#
Bit #* Hex # Bit #
Byte
#
Bit #
Definition Usage Notes
27 8 3 10 25 0 30 0
Window 45
Warning Flag
0 = Pass
1 = Fail
27 9 3 11 25 1 30 1
Window 45
Fault Flag
0 = Pass
1 = Fail
27 10 3 12 25 2 30 2
Window 46
Warning Flag
0 = Pass
1 = Fail
27 11 3 13 25 3 30 3
Window 46
Fault Flag
0 = Pass
1 = Fail
27 12 3 14 25 4 30 4
Window 47
Warning Flag
0 = Pass
1 = Fail
27 13 3 15 25 5 30 5
Window 47
Fault Flag
0 = Pass
1 = Fail
27 14 3 16 25 6 30 6
Window 48
Warning Flag
0 = Pass
1 = Fail
27 15 3 17 25 7 30 7
Window 48
Fault Flag
0 = Pass
1 = Fail
28 0 4 0 26 0 33 0
Gage 33
Warning Flag
0 = Pass
1 = Fail
28 1 4 1 26 1 33 1
Gage 33
Fault Flag
0 = Pass
1 = Fail
28 2 4 2 26 2 33 2
Gage 34
Warning Flag
0 = Pass
1 = Fail
28 3 4 3 26 3 33 3
Gage 34
Fault Flag
0 = Pass
1 = Fail
28 4 4 4 26 4 33 4
Gage 35
Warning Flag
0 = Pass
1 = Fail
28 5 4 5 26 5 33 5
Gage 35
Fault Flag
0 = Pass
1 = Fail
28 6 4 6 26 6 33 6
Gage 36
Warning Flag
0 = Pass
1 = Fail
28 7 4 7 26 7 33 7
Gage 36
Fault Flag
0 = Pass
1 = Fail
