Rockwell Automation 5370 Color CVIM Communications Manual User Manual
Page 164
(Host Input & Output Bits)
Appendix B
Discrete Bit Results Bits
B–10
Table B.1
Discrete Bit Inputs (Cont’d)
PI Backplane
Remote I/O
RS–232 ASCII
RS–232 DF1
Word
#
Bit #
Word
#
Bit #*
Hex #
Bit #
Byte
#
Bit #
Definition
Usage
Notes
23
8
7
10
17
0
22
0
Gage 29
Warning Flag
0 = Pass
1 = Fail
23
9
7
11
17
1
22
1
Gage 29
Fault Flag
0 = Pass
1 = Fail
23
10
7
12
17
2
22
2
Gage 30
Warning Flag
0 = Pass
1 = Fail
23
11
7
13
17
3
22
3
Gage 30
Fault Flag
0 = Pass
1 = Fail
23
12
7
14
17
4
22
4
Gage 31
Warning Flag
0 = Pass
1 = Fail
23
13
7
15
17
5
22
5
Gage 31
Fault Flag
0 = Pass
1 = Fail
23
14
7
16
17
6
22
6
Gage 32
Warning Flag
0 = Pass
1 = Fail
23
15
7
17
17
7
22
7
Gage 32
Fault Flag
0 = Pass
1 = Fail
24
0
0
0
18
0
25
0
Not Used
24
1
0
1
18
1
25
1
Configuration
Error
0 = No Error
1 = Error
Configuration error bit is set after
any invalid configuration block
write to the Color CVIM. This
flag is set after validation errors.
24
2
0
2
18
2
25
2
Mastership
Flag
0 = Not Master
1 = Master
The device which reads this bit
as 1 is the host. Not applicable
for RS–232 communications.
24
3
0
3
18
3
25
3
Module Busy
0 = Not Busy
1 = Busy
Module Busy bit is set during the
SETUP mode and while sending
a configuration download to the
Color CVIM.
24
4
0
4
18
4
25
4
Trigger NAK
0 = OK
1 = Trigger 1
Missed
24
5
0
5
18
5
25
5
Post Results
0 = Part 1
1 = Part 2
24
6
0
6
18
6
25
6
Toolset
Data Valid
0 = Not Valid
1 = Results Valid
Data Valid bit is reset when a
user enters the SETUP mode
and when pulsed output duration
has expired Refer to Chapter 3.
24
7
0
7
18
7
25
7
Not Used
