Data Tables 49
Read word 4
Bits 00…14
(00…16)
Channel 4 analog data – 12-bit left justified two's
complement number; unused lower bits are zero;
4…20 mA uses all 16 bits.
Bit 15 (17)
Channel 4 analog data sign bit.
Read word 5
Bits 00…14
(00…16)
Channel 5 analog data – 12-bit left justified two's
complement number; unused lower bits are zero;
4…20 mA uses all 16 bits.
Bit 15 (17)
Channel 5 analog data sign bit.
Read word 6
Bits 00…14
(00…16)
Channel 6 analog data – 12-bit left justified two's
complement number; unused lower bits are zero;
4…20 mA uses all 16 bits.
Bit 15 (17)
Channel 6 analog data sign bit.
Read word 7
Bits 00…14
(00…16)
Channel 7 analog data – 12-bit left justified two's
complement number; unused lower bits are zero;
4…20 mA uses all 16 bits.
Bit 15 (17)
Channel 7 analog data sign bit.
Read word 8
Bits 00…14
(00…16)
Channel 8 analog data – 12-bit left justified two's
complement number; unused lower bits are zero;
4…20 mA uses all 16 bits.
Bit 15 (17)
Channel 8 analog data sign bit.
Read word 9
Bits 00…14
(00…16)
Channel 9 analog data – 12-bit left justified two's
complement number; unused lower bits are zero;
4…20 mA uses all 16 bits.
Bit 15 (17)
Channel 9 analog data sign bit.
Read word 10
Bits 00…14
(00…16)
Channel 10 analog data – 12-bit left justified two's
complement number; unused lower bits are zero;
4…20 mA uses all 16 bits.
Bit 15 (17)
Channel 10 analog data sign bit.
Read word 11
Bits 00…14
(00…16)
Channel 11 analog data – 12-bit left justified two's
complement number; unused lower bits are zero;
4…20 mA uses all 16 bits.
Bit 15 (17)
Channel 11 analog data sign bit.
Word/Bit Descriptions – 1794-IE12 Analog Input Module
Word
Decimal Bit
(Octal Bit)
Definition
