20 Install Your FLEX I/O Module
4. If daisy chaining +V power to the next terminal base unit, connect a
jumper from terminal 50 (+VDC power) on this base unit to the +VDC
terminal on the next terminal base unit, and connect a jumper from
terminal 51 (-VDC common) on this base unit to the common terminal
on the next terminal base unit.
5. If continuing -V common to the next terminal base unit, connect a jumper
from terminal 51 (-VDC common) on this base unit to the to the common
terminal on the next terminal base unit.
Wire Connections for 1794-TB3G, and 1794-TB3GS using the 1794-IE12 Module
Channel Signal Type Label
Markings 1794-TB3G and 1794-TB3GS
Input Common Terminal
Input 0 Current I A-0 B-17
Voltage V A-1
Input 1 Current I A-2 B-18
Voltage V A-3
Input 2 Current I A-4 B-23
Voltage V A-5
Input 3 Current I A-6 B-24
Voltage V A-7
Input 4 Current I A-8 B-25
Voltage V A-9
Input 5 Current I A-10 B-26
Voltage V A-11
Input 6 Current I A-12 B-31
Voltage V A-13
Input 7 Current I A-14 B-32
Voltage V A-15
Input 8 Current I B-19 C-37
Voltage V B-20
Input 9 Current I B-21 C39
Voltage V B-22
Input 10 Current I B-27 C-46
Voltage V B-28
Input 11 Current I B-29 C-48
Voltage V B-30
