12–3
Publication 2755-838
This section shows how to download a configuration to one or more
Readers. Verify that your computer is connected to a Reader as
shown on previous page.
To download a configuration to a Reader:
1. Run the AdaptaScan software.
The AdpataScan database dialog opens.
Highlight
Project
2. Select and open the project containing the configuration you want
to download.
3. From the Communications menu, select Go-Online.
The Reader will be detected (if properly connected) and displayed
in the project window.
4. Make sure each device within the project has a unique DeviceNet
address (even if you are not using DeviceNet communications).
With the Reader name highlighted, click the Device button to
open the Device dialog and set the address. Click Apply to send
the address to the Reader.
If the Device is online but not in the project
database, the following dialog is displayed:
If the Device is online and in the current project
database, the following dialog is displayed:
Set to
Unique
Address
5. From the Project window, select the Reader or Readers to which
you want to download a configuration. To select multiple
Readers, hold down the the [Shift] or [Ctrl] control keys while
making the selections. [Shift] selects a group of consecutive
listings and [Ctrl] selects nonconsecutive listings.
Downloading
a Configuration
