Chapter
7
Decoder Setup
This chapter configures the operation of the Reader’s decoder.
Section Page
Helpful Hints 7–1
Decoding Functions 7–1
Valid Symbologies 7–2
When Decoding Occurs 7–3
Capture Count 7–5
Setting Decode Parameters 7–6
Configuring the Performance Indicator 7–8
Viewing Readers with the Same Trigger Source 7–10
When configuring the Reader’s decode functions:
•
Enable only the bar code symbologies the Reader will scan to
increase decode speed and reduce misreads.
•
During initial setup, use the Self-Triggered decode option and
specify an Inter-Symbol No-Read Count. The Reader will
continuously attempt to decode data.
•
To prevent misreads, trigger decoding only when a bar code label
is within the scan area of the Reader.
The Decoder dialogs define:
•
When the Reader decodes bar code symbols from the scanner.
•
What bar code symbologies are decoded.
•
Minimum performance level before an alarm occurs.
Chapter Objectives
Helpful Hints
Decoding Functions
