11–20

Publication 2755-838

The Used By dialog lists other Readers that use the package or match
table configurations as trigger sources. Use this dialog when you
make changes to a match table / package definition and you want to
view or access configurations assigned to the same trigger source.
Open the Used By dialog by clicking the Used By button on the
Match Table or Packages dialog.

Currently Used By

Displays the Reader configurations that use the same package or
match table trigger source. Highlight the package or match table
definitions you want to access and click the Goto button.

Viewing Readers
with Same Trigger Source

☞

Or double-click the package or
match table definition and then
click the Goto button.
