8–3
Publication 2755-838
Two dialogs define DeviceNet parameters, one defines the baud rate
of the project, the other defines a Reader address within the project.
Project Dialog
The Project dialog defines the baud rate for all Readers on the same
DeviceNet network. The project name and description fields are
defined on page 2–17. The Project dialog opens whenever you open
a new project or when selecting Edit from the Project menu.
DeviceNet Baud Rate
Select a rate for all Readers defined within the project.
Baud Rate: Supports maximum cable length of:
125 Kbps 1600 feet (500 meters)
250 Kbps 600 feet (200 meters)
500 Kbps 300 feet (100 meters)
Configuring
DeviceNet Parameters
