161
Appendix
D
Troubleshooting Display and Status
Indicators
This section covers problems that may occur with your 1756-RIO module.
The following areas are covered:
• 1756-RIO module’s alphanumeric display
• RIO status indicator
• CLX status indicator
• OK status indicator
• Debug log
• Fatal errors
• Updating the firmware
Alphanumeric Display
The 4-character, alphanumeric display shows ‘RIO Scanner’, or ‘RIO Adapter’,
followed by the firmware version number, and any banner text defined in the
module configuration.
The display shows the following messages at power-up.
If the indicator on the 1756-RIO module does not cycle through these
messages on powerup, contact Technical Support.
Message
Description
B#nn
Stages in the start-up processes; nn is a hexadecimal number
Boot
Next stage in power-up sequence
RIO Scanner v. x.xx.xx Module firmware revision
