32 Blow-molding Module

Publication 1746-IN014B-EN-P - January 2001

Output Image

Note:

For description definitions, see page 43.

Addresses for axes 1-4

axis 1

axis 2

axis 3

axis 4

Control-bit Description (1 = enable)

0/0

2/0

4/0

6/0

profile-enable

0/1

2/1

4/1

6/1

hold-value-0

0/2

2/2

4/2

6/2

hold-value-1

0/3

2/3

4/3

6/3

hold-value-2

0/4

2/4

4/4

6/4

download axis control structure (from SLC)

0/5

2/5

4/5

6/5

upload axis control structure (to SLC)

0/6

2/6

4/6

6/6

record current axis position as zero-scale calibration

0/7

2/7

4/7

6/7

record current axis position as full-scale calibration

0/8

2/8

4/8

6/8

download setpoint profile (from SLC)

0/9

2/9

4/9

6/9

upload process-variable profile (to SLC)

0/10

2/10

4/10

6/10

download master setpoint profile (from SLC)

0/11

2/11

4/11

6/11

upload interpolated setpoint profile (to SLC)

0/12

2/12

4/12

6/12

synch input

0/13

2/13

4/13

6/13

synch output

0/14

2/14

4/14

6/14

parison weight control

0/15

2/15

4/15

6/15

accumulator velocity control

reserved

hold-value “0”

hold-value “1”

hold-value “2”

high speed analog input word (see page 12)

21 – 31

reserved
