Blow-molding Module 29

Publication 1746-IN014B-EN-P - January 2001

Using M0/M1 Files

The module’s M0 file receives axis-control structures and axis profiles from your
designated N files. The module returns to designated N files:

axis-control structures for verification

process-variable profiles to indicate how setpoint profiles were executed

Your ladder logic must move this data between N files and M0/M1 files.

M0 file - write blocks to the BLM module

M1 file - read blocks from the BLM module

Words

Description

0-63

Control structure for axis 1 (see next page for listing)

64-127

Control structure for axis 2

128-191

Control structure for axis 3

192-255

Control structure for axis 4

256-511

Setpoint profile for axis 1

512-767

Setpoint profile for axis 2

768-1023

Setpoint profile for axis 3

1024-1279

Setpoint profile for axis 4

1280-1535

Master Setpoint profile

Words

Description

0-63

Control structure for axis 1 (see next page for listing)

64-127

Control structure for axis 2

128-191

Control structure for axis 3

192-255

Control structure for axis 4

256-511

Process-variable profile for axis 1

512-767

Process-variable profile for axis 2

768-1023

Process-variable profile for axis 3

1024-1279

Process-variable profile for axis 4

1280-1535

Interpolated setpoint profile

1536

Module’s firmware revision (in BCD)

Note: M1 control structure files are returned in engineering units.
