Blow-molding Module 3
Publication 1746-IN014B-EN-P - January 2001
Recommendation for using associated software
To program the SLC processor to interface the module with molding machine
operation, your PC should be equipped with programming software RSLogix 500™
from Rockwell Software. For instructions on using the software, refer to the
documentation that accompanied it.
What you need to do to set up and operate the module?
This document covers a description of the module and its operation, wiring and
configuring the module, writing ladder logic and using associated data files,
calibrating, tuning, troubleshooting, and specifications.
Step
Description
Page
1
2
Machine applications of the module
3
Module operation with an accumulator machine
4
Module operation with a continuous extrusion machine
5
6
7
Configuring the SLC processor (including I/O, M0/M1, and G file)
8
Axis Control Structures in M0/M1 Files
9
Using output and input image tables
10
11
12
13
Descriptions of module parameters
