Important – Rockwell Automation 1746-BLM Blow Molding Module Installation Instructions User Manual
Page 28
28 Blow-molding Module
Publication 1746-IN014B-EN-P - January 2001
You may set bits by entering an equivalent bit-set word in hex.
For example, a hex value of 0062 represents:
IMPORTANT
Before operating the module for the first time, you must
download the G file to the module. Do this by downloading
your ladder file, even if it contains no rungs. The SLC
processor must be in Program mode for a download.
axis profile size of 256 setpoints (bits 15-08 = 256 = 00)
axis synch input and output controlled by SLC
(bits 07-04 = 0 1 1 0 = 6)
accumulator driven by independent position-based axis 0
(bits 03-00 = 0 0 1 0 = 2)
0062
