Page 59: Specifications, Appendix

59
Publication 1758-UM001D-EN-P - June 2011
Appendix
A
Specifications
This appendix provides the following information:
•
•
Controller Specifications
General
Attribute
Value
Dimensions
213 x 133 x 56 mm
8.375 x 5.25 x 2.20 in.
Number of I/Os
8 digital inputs
4 digital outputs
8 analog inputs
2 analog outputs
3 pulse inputs
Power supply voltage
12V DC, (-15%, +10%)
Power consumption
80…120 mA
Heat dissipation, nom.
< 1.2 W
Input circuit type
Current Sinking
Output circuit type
Current Sourcing (FET)
Terminal screw torque
0.8 mm (7 in-lb)
Wire size
0.34... 2.5 mm² (22...12 AWG) solid or stranded copper wire
rated at 90 °C (194 °F ) or greater 1.2 mm (3/64 in.)
insulation max
