B-4 Worksheets
Optional Memory Module
Selection (Jumper JW3)
See Figure 3.1 for the locations of the four jumpers.
See Figure 3.4 for jumper JW3 pin assignments and settings.
Specify the optional memory module selection for the system by
filling in the table below.
What to Do Next
Give a copy of this worksheet to the hardware installer. Store this
worksheet with your application program for future reference.
Memory Module Option
Optional
Memory
Module
Selection
Corresponding Jumper
Position on JW3
1747-M1 8 KB EEPROM (1746-BAS module
only)
Across pins 1 and 3, 2 and 4
1747-M2 32 KB EEPROM (1746-BAS module
only)
Across pins 1 and 3, 2 and 4
1747-M3 8 KB UVPROM (1746-BAS module
only)
Across pins 1 and 3, 2 and 4
1747-M4 32 KB UVPROM (1746-BAS module
only)
Across pins 3 and 5, 4 and 6
1771-DBMEM1 8 KB EEPROM (1746-BAS-T
module only)
Across pins 1 and 3, 2 and 4
1771-DBMEM 32 KB EEPROM (1746-BAS-T
module only)
Across pins 1 and 3, 2 and 4
