Port prt2 configuration (jumper jw2), What to do next – Rockwell Automation 1746-BAS-T SLC 500 Basic Basic-T Modules User Manual
Page 77
Publication 1746-UM004B-EN-P - December 2005
Worksheets B-3
Port PRT2 Configuration
(Jumper JW2)
See Figure 3.1 for the locations of the four jumpers.
See Figure 3.3 for jumper JW2 pin assignments and settings.
Specify the configuration of port PRT2 on your module by filling in
the table below.
What to Do Next
Give a copy of this worksheet to the hardware installer. Store this
worksheet with your application program for future reference.
Port
Configuration
Selection
Corresponding Jumper Position on
JW2
PRT2
RS-232/423
Across pins 1 and 2, 3 and 4
RS-422
Across pins 5 and 6, 7 and 8
RS-485
Across pins 7 and 8, 9 and 10
