Page 71: Module hardware specifications -1, Appendix

1
Publication 1746-UM004B-EN-P - December 2005
Appendix
A
Specifications
Module Hardware
Specifications
The module hardware specifications are listed in the following tables.
Specification
Value
Power Supply Loading at
5V dc
0.150 A (module only)
0.150 A (module with link coupler)
Power Supply Loading at
24V dc
0.070 A (module only)
0.125 A (module with link coupler)
(2)
(2)
If a Hand-held Terminal, Data Table Access Module, or interface converter is connected to the link coupler,
the additional backplane power draw of these components must be added to the 0.125 listed in the table
above. This only applies when the module is connected to the network via the link coupler and 1747-C10
cable or 1747-C11 cable. This does not apply when the 1747-C13 cable is used.
Noise Immunity
NEMA Standard ICS 2-230
Vibration
Displacement: 0.015 in., peak-to-peak at 5...57 Hz
Acceleration: 2.5 g at 57...2000 Hz
Shock (operating)
30 g
Port Isolation
(1)
Port PRT1
Port PRT2
Port PRT1 to Port PRT2
(1)
Port DH485 is not isolated.
710V dc for 1 minute (backplane to port)
710V dc for 1 minute (backplane to port)
710V dc for 1 minute (port PRT1 to port PRT2)
Ambient Temperature
Rating
Operating: 0...+60 °C (+32...+140 °F)
Storage: -40...+85 °C (-40...+185 °F)
Humidity
5...95% without condensation
Clock/Calendar Accuracy
±1 minute/month at 25 °C (77 °F)
+0, -6 minute/month at 60 °C (140 °F)
Certification
Value
Agency Certification
c-UL-us listed
Class I, Groups A, B, C or D, Division 2
CE compliant for all applicable directives
C-Tick marked for all applicable acts
