Publication 1746-UM004B-EN-P - December 2005
Programming Overview 4-5
Refer to the BASIC Language Reference Manual, publication
1747-RM001, for additional information on these commands.
BASIC Statements
BASIC statements are programming instructions that are executed
during Run mode. Typically these statements are used to control
program execution. The following table lists the BASIC programming
statements.
Statement
Function
Examples
CLEAR
CLEAR variables, interrupts, and strings.
CLEAR
CLEAR (S&I)
CLEAR stacks and interrupts.
CLEARS, CLEARI
CLOCK (1&0)
Enable and disable free running clock.
CLOCK1, CLOCK0
DATA
Read information with the DATA statement.
DATA 100
DIM
Allocate memory for arrayed variables.
DIM A(20)
DO-WHILE
Set up loop for WHILE.
DO - WHILE
DO-UNTIL
Set up loop for UNTIL.
DO - UNTIL
END
Terminate program execution.
END
FOR-TO-STEP
Set up FOR-NEXT loop.
FOR A = 1 TO 5
GOSUB
Execute subroutine.
GOSUB 1000
GOTO
GOTO program line number.
GOTO 500
IF-THEN-ELSE
Test for a condition.
IF A>B THEN A=0
INPUT
INPUT a string or variable.
INPUT A
LD@
Load top of stack from user specified location.
LD@ 1000H, LD@ A
LET
Assign a variable or string a value. (LET is optional.)
LET A=1
NEXT
Test FOR-NEXT loop condition.
NEXT A
ONERR
Perform conditional arithmetic ERROR handling.
ONERROR 10
ON-GOTO
Perform conditional GOTO.
ON A GOTO 5, 20
ON-GOSUB
Perform conditional GOSUB.
ON A GOSUB 6, 2
ONTIME
Generate an interrupt when TIME is equal to or
greater than the expression following ONTIME
statement.
ONTIME10, 1000
PH0.
PRINT HEX mode with zero suppression.
PH0. A
PH1.
PRINT HEX mode without zero suppression.
PH1. A
POP
POP argument stack to variables.
POP A, B, C
PRINT variables, strings or literals.
PRINT A
PUSH
PUSH expressions on argument stack.
PUSH 10, A
READ
READ data in a DATA statement.
READ A
REM
Insert a remark statement in a program.
REM DONE
RESTORE
RESTORE READ pointer.
RESTORE
