Appendix
B
Worksheets
This appendix contains important information you should be
concerned with when configuring the module. The information is
general in nature and supplements specific information contained in
earlier chapters of this manual.
Topics include worksheets for configuring:
• the BASIC or BASIC-T module.
• jumpers JW1-JW4.
Module Configuration
Specify the connection information by filling in the boxes in the figure
below.
Figure B.1 Module Configuration
PR T1
5
4
3
2
1
9
8
7
6
PR T2
5
4
3
2
1
9
8
7
6
DH485
BASIC
Connected Device: YES______ NO ______
Device Type: _______________________
Protocol: __________________________
Program Port: YES______ NO ______
Connected Device: YES______ NO ______
Device Type: _______________________
Protocol: _________________________
Connected Device: YES______ NO ______
Device Type: _______________________
Protocol: __________________________
Program Port: YES______ NO ______
IMPORTANT
When DF1 protocol is selected for port PRT2, the
DH485 port is not available for programming or
runtime operation.
