5–6

Channel Configuration, Data, and Status

Publication 1746Ć6.8 - April 1997

Channel Data Word Values for Scaled Data

Input Type

Signal Range

ScaledĆforĆPID

Proportional Counts (default)

NI4 Data Format

±

10V dc

-10.00V to +10.00V

0 to 16383

-32768 to 32767

-32768 to 32767

0-5V dc

0.0V to +5.00V

0 to 16383

-32768 to 32767

0 to 16384

1-5V dc

+1.00V to +5.00V

0 to 16383

-32768 to 32767

3277 to 16384

0-10V dc

0.0V to +10.00V

0 to 16383

-32768 to 32767

0 to 32767

0-20 mA

0.0 mA to 20.0 mA

0 to 16383

-32768 to 32767

0 to 16384

4-20 mA

4.0 mA to 20.0 mA

0 to 16383

-32768 to 32767

3277 to 16384

±

20 mA

-20.0 mA to 20.0 mA

0 to 16383

-32768 to 32767

-16384 to 16384

0-1 mA

0.0 mA to 1.00 mA

0 to 16383

-32768 to 32767

0 to 1000

This data format is not supported by the 1746ĆNI4 module, but is available for the 1746ĆNI8 module.

This section provides descriptions of how the data types are
expressed in the channel data word and examples of how to
mathematically convert the data.

Data Type Descriptions

The engineering units are 1 mV/step for voltage input types, and
1.0

µ

A/step for current input types.

The scaled-for-PID value is a 14-bit unsigned integer, with 0
representing the low scale value and 16,383 representing the full
scale value minus 1 lsb. The input signal range is proportional to
your selected input type and scaled into a 0–16,383 range, which is
standard to the SLC PID algorithm.

The proportional count value is a 16-bit signed integer. The input
signal range is proportional to your selected input and scaled into a
–32,768 to 32,767 range.

The 1746-NI4 data format converts the current and voltage signals
into 16-bit 2’s complement binary values. The table below identifies
the current and voltage input ranges for the input channels, the
number of significant bits, and the resolution.

Voltage/Current Range

Decimal

Representation

Number of

Significant Bits

Resolution

per LSB

-10V dc to +10V dc - 1LSB

-32,768 to +32,767

16 bits

0 to 5V dc

0 to 16,384

14 bits

305 176 V

1 to 5V dc

3,277 to 16,384

13.67 bits

305.176 uV

0 to 10V dc - 1LSB

0 to 32,767

15 bits

Scaling the

Channel Data Word
