Specifications
Specifications - 1734-ADN(X) DeviceNet Adapter Module
Communication Interface Specifications
Expansion I/O Capacity
Up to 13 modules (13 times 75mA = 0.975, just under
the limit of 1.0A). The actual number of modules can
vary. Add up the current requirements of the
modules you want to use to make sure they do not
exceed the amperage limit of the 1734-ADN. (Note:
Total expansion up to 63 modules - 13 modules
maximum with 1734-ADN - add 1734-EP24DC
modules for an additional 17 modules (or less based
on current requirements), up to 63 module maximum)
Cat. No.
PointBus Current Requirements
1734-232ASC
75mA
1734-485ASC
75mA
1734-IB2
75mA
1734-IB4
75mA
1734-IV2
75mA
1734-IV4
75mA
1734-OB2E
75mA
1734-OB2EP
75mA
1734-OB4E
75mA
1734-OV2E
75mA
1734-OV4E
75mA
1734-OW2
80mA
1734-OX2
100mA
1734-IE2C
75mA
1734-OE2C
75mA
1734-IE2V
75mA
1734-OE2V
75mA
1734-IA2
75mA
1734-IM2
75mA
1734-OA2
75mA
1734-IJ2
160mA
1734-IK2
160mA
1734-IR2
220mA
1734-SSI
110mA
1734-IT2I
175mA
1734-VHSC5
180mA
1734-VHSC24
180mA
DeviceNet Communication Rate
125K bit/s (500m maximum)
250K bit/s (250m maximum)
500K bit/s (100m maximum)
DeviceNet Cable
Allen-Bradley part number 1485C-P1-Cxxx
Refer to publication DN-2.5 for more information
Module Location
Starter module - left side of 1734 system
